Item names and technical data
8 Snow depth sensor SHM 31, V2.1
2.2. Technical data
Category
Name
Value
Measuring parameters
Snow depth
0 – 15 m
Accuracy
± (5 mm + 0.06%)
Repeatability
0.6 mm
Precision, reproducibility
5 mm
Signal intensity (normalised)
0 – 255
Installation
Assembly height / measuring
distance
0.1 – 16 m
Tilt angle to the vertical position
10 – 30 degrees
Data interface
RS485
- UMB binary protocol (19200 Bd, variable)
- UMB-ASCII 2.0
- Modbus RTU
- Modbus ASCII
SDI-12
- SDI-12 protocol
RS232
- UMB-ASCII 2.0 protocol (9600 Bd, fixed)
RS485 and SDI-12 share the same connectors and cannot be used in parallel. RS232 uses separate
connectors and can be operated in parallel with RS485 or SDI-12.
Data transfer
Polling: UMB, UMB-ASCII 2.0, SDI-12,
Modbus
Auto Send function: UMB-ASCII 2.0
Operating parameters
Temperature range:
Without heating:
-40°C – + 50°C
-10°C – +50°C (laser inactive < -15°C)
Rel. humidity
0 – 100%
Power supply
12 or 24 V DC, tolerance ±15%
Connected load with heating
18 W
Average consumption without
heating
0.7 W
Average consumption with 10 s
measurement interval and window
heating switched on
3.4 W
MTBF @ 25°C / 40°C
88,000 h / 50,000 h
Connection cable length while using
the RS232 interface
1
≤ 15 m
Safety
Laser safety
Laser Class 2 (IEC 60825-1:2014)
Protection rating
IP68
EMC
EN 61326-1:2012 (industrial standard)
EU Directive
EMC 2014/30/EU, ROHS 2011/65/EU
Size, weight
Sensor size (LxWxH)
302 x 130 x 234 mm
Sensor weight
2.35 kg
Packaging size
400 x 240 x 180 mm
Weight incl. packaging
3.4 kg
Storage conditions
Temperature; rel. humidity
T={-25°C – +70°C}; rH < 100%
Table 2 2: Technical data
1
If connection cables > 15 m are used, transfer problems may occur over RS232. Additionally, the voltage
drop over the cable length must be taken into account.
