For both European and non-European type blade guards
The riving knife installing location is factory-adjusted so that the blade and riv-
ing knife will be in a straight line. However, if they are not in a straight line,
loosen the hex bolts (B) and adjust the blade guard mounting portion (stay) so
that the riving knife is aligned directly behind the blade. Then tighten the hex
bolts (B) to secure the stay.
CAUTION:
• If the blade and riving knife are not aligned properly, a dangerous
pinching condition may result during operation. Make sure they are
properly aligned. You could suffer serious personal injury while using the
tool without a properly aligned riving knife.
• NEVER make any adjustments while tool is running. Disconnect the tool
before making any adjustments.
There must be a clearance of about 4 - 5 mm between the riving knife and the
blade teeth. Adjust the riving knife accordingly and tighten the hex bolts (A)
securely. Attach the table insert on the table, then check to see that the blade
guard works smoothly before cutting.
Installing and adjusting rip fence
1) Fit the hook on the tip of the rip fence into the far guide rail on the table or
sub table (R) and install and push the rip fence forward so that the fence
holder engages with the nearmost guide rail.
To slide the rip fence on the guide rail sideways, pivot the knob on the fence
holder to the half way of its travel.
To secure the rip fence, pivot fully the knob on the fence holder.
2) To slide the rip fence on the guide rail sideways, return the knob on the
fence holder fully without pulling the lever on the knob.
3) To remove it, pull the lever on the knob and pivot the knob fully forward while
pulling the lever.
1. Blade
2. These two clearances should be
equal.
3. Riving knife
4. Hex bolts (B)
5. Hex bolts (A)
1
2
3
4
5
006223
1. Riving knife
2. Blade guard
4-5mm
2
1
006209
1. Hook
2. Knob
3. Guide rail
1
3
2
006159
