Commissioning and operation
82
Control engines at the same engine speed
1. Set both levers in the range between “Ahead" and “Full ahead" (max. deviation of the levers from each
other 10%).
2. Press button.
Both engines are regulated to the same engine speed. The LEDs light.
Note:
If the levers are moved out of synch. with each other by more than 10%, then the “SYNCHRO"
mode reverts to Stand-by mode. As soon as the levers are again positioned less than 10% away
from each other, the synchronisation becomes effective again.
Adjust engine speeds with a single lever
1. Position the lever in the “Ahead" detent.
2. Press button.
The LEDs light. Both engines are engaged at idle.
Increase speed of all engines:
3. Push the lever of the master system forward.
The LED of the master system remains lit, the LED of the slave system goes out.
Note:
If the speed of the slave system is increased, the “SYNCHRO" function reverts to the Stand-by
mode. As soon as the levers are again positioned less than 10% away from each other, the syn
chronisation becomes effective again.
and
1. Set both levers in the range between “Ahead" and “Full ahead" (max. deviation of the levers from each
other 10%).
2. Press button.
The LEDs light. Both engines are engaged.
3. Move the lever of the slave system quickly to the “Ahead" detent.
The LED of the master system remains lit, the LED of the slave system goes out.
If the slave system lever is moved too slowly, then the “SYNCHRO" function reverts to the Stand-by mode.
Both LEDs light, because the port and starboard sides are not synchronised.
As soon as the levers are again positioned within 10% of each other, the process is repeated.
