Spare parts required for maintenance
11.3 Spare parts for the carrier
25.11.2016
Maintenance manual 3 302 364 en 11 - 5
GMK 4100L-1
11.3 Spare parts for the carrier
Assemblies and spare parts
Carrier
GROVE-
part number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Engine
Air filter – main filter
Air filter – back-up filter
04158601
1 item when the symbol lights up
04158602
Fuel system
Filter (filter 1; large)
04161991 1
Filter (filter 2; small) 04161566 1
Transmission
Gasket 24 x 29 Cu DIN 7603
00117145 1
Transfer case
Gasket 30 x 36 Cu DIN 7603
00117151 1 1
Gasket 16 x 20 Cu DIN 7603 00117134 1
Angle gear
Gasket 30 x 36 Cu DIN 7603
00117151 1 1
Filter
Packing set
03135866 1
04161645 1
Screw with gasket (oil cooler) 03326356 1
Axle lines Axle centre drive (for max. 8 x 8 x 8)
Gasket 30 x 36 Cu DIN 7603
00117151 4 4
Gasket 24 x 29 Cu DIN 7603 00117145 2
Gasket 36 x 42 Cu DIN 7603 01371208 4
Axle lines Final drive (for max. 8 x 8 x 8)
Gasket 24 x 29 Cu DIN 7603
00117145 8 8
