Manitowoc National Crane NBT40 Series User Manual

National Crane Published 4-23-2018 Control # 239-11 5-1
5
NBT40 SERIES OPERATOR MANUAL LUBRICATION
SECTION 5
LUBRICATION
SECTION CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Environmental Protection . . . . . . . . . . . . . . . . . . . 5-1
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Arctic Conditions Below -9°C (15°F). . . . . . . . . . . 5-1
Chassis Grease . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Low Temperature Grease . . . . . . . . . . . . . . . . . . . 5-2
Extreme Pressure Multipurpose Gear
Lubricant (EPGL) . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Open Gear Lubricant . . . . . . . . . . . . . . . . . . . . . . 5-2
Antifreeze/Coolant (for Cab Heater) . . . . . . . . . . . 5-2
Anti-wear Additives . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Standard Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . 5-2
Arctic Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Hydraulic Oil Inspection . . . . . . . . . . . . . . . . . . . . 5-3
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Boom Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Internal Cable Sheave Lubrication. . . . . . . . . . . . . 5-6
Side and Bottom Boom Wear Pad Lubrication . . . 5-7
Top Boom Wear Pad Lubrication. . . . . . . . . . . . . . 5-7
Outrigger Beam Lubrication. . . . . . . . . . . . . . . . . . 5-7
Hoist Brake Oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Hoist Gearbox Oil . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Swing Gearbox and Brake Oil . . . . . . . . . . . . . . . . 5-9
Hydraulic Oil Reservoir Level . . . . . . . . . . . . . . . . 5-9
Air Conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Wire Rope Lubrication . . . . . . . . . . . . . . . . . . . . . 5-10
Carwell® Rust Inhibitor. . . . . . . . . . . . . . . . . . . . . 5-11
Protecting Cranes From Rusting . . . . . . . . . . . . . 5-11
Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . 5-11
Inspection and Repair . . . . . . . . . . . . . . . . . . . . . 5-12
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Areas of Application. . . . . . . . . . . . . . . . . . . . . . . 5-13
GENERAL
Following the designated lubrication procedure is important
in ensuring maximum crane lifetime and utilization. The
procedures and lubrication charts in this section include
information on the types of lubricants used, the location of
the lubrication points, the frequency of lubrication, and other
information. The information included in this section does not
include lubrication requirements for the truck chassis. Refer
to appropriate truck manufacturer's manual for this
information.
ENVIRONMENTAL PROTECTION
Dispose of waste properly! Improperly disposing of waste
can threaten the environment.
Potentially harmful waste used in Manitowoc cranes includes
— but is not limited to — oil, fuel, grease, coolant, air
conditioning refrigerant, filters, batteries, and cloths which
have come into contact with these environmentally harmful
substances.
Handle and dispose of waste according to local, state, and
federal environmental regulations.
When filling and draining crane components, observe the
following:
• Do not pour waste fluids onto the ground, down any
drain, or into any source of water.
• Always drain waste fluids into leak proof containers that
are clearly marked with what they contain.
• Always fill or add fluids with a funnel or a filling pump.
Immediately clean up any spills.
The service intervals specified are for normal operation
where moderate temperature, humidity, and atmospheric
conditions prevail. In areas of extreme conditions, the
service periods and lubrication specifications should be
altered to meet existing conditions. For information on
extreme condition lubrication, contact your local National
Crane Distributor or Manitowoc Crane Care.
Lubricants
Specific recommendations of brand and grade of lubricants
are not made here due to regional availability, operating
conditions, and the continual development of improved
products. Where questions arise, contact your National
Crane Distributor or Manitowoc Crane Care.
