2017 OWNERS MANUAL / 130
a selection of soft keys. Soft key commands provide additional
features and navigation shortcuts. Depending on the current screen
displayed, the soft keys may appear as icons or as a vertical control
bar.
4.5” Touch Screen
The 4.5” touch screen functions can be accessed through the Quick
Access Keys on the left and right of the display screen or operated
through the touch screen.
Although most of the functionality is available through touching
the screen, not everything can be accessed in that manner. For
example, menu items displayed on the screen are accessible only
through the Quick Access Keys. The following controls are accessed
via the Quick Access Keys: Lights, climate control, video control,
SCREENS
4.5” Static, Non-Touch Screen
The 4.5” static, non-touch screen displays the gauges associated
with the engine in both the gauge view and the digital view.
It also displays the video. The following displays can be accessed via
the Quick Access Keys: Gauges, digital gauges and video on the 7”
touch screen.
7” Non-Touch Screen
The following controls are accessed via the Quick Access Keys:
Cruise control, skier profiles, stereo, GPS, home, cruise ON/OFF,
scroll up and scroll down. When the Menu key is pressed once,
the “On Screen Menu” is displayed on both the 7” and 4.5” touch
screens. When the Menu key is pressed and held, the Main Menu is
displayed and provides access to the settings menu through
PRODUCT INFORMATION FOR
THE XSTAR VIDEO TOUCH AND
STATIC (NONTOUCH) SCREENS
The XStar video screens consist of one (1) 4.5” video touch screen,
one (1) 4.5” static, non-touch screen, and one (1) 7” touch screen. A
unique feature is that the 4.5” video touch screen and the 7” touch
screen are linked.
Some changes made on either are displayed on both. The 4.5”
static, non-touch screen is independent of the other two screens
and displays engine and transmission parameters and service
codes. These are multi-functional tools that provide GPS tracking,
multi-media display, cruise control, rider profiles, and enables equip-
ment operators to view a wide range of engine, ballast, transmission
parameters and service codes.
CARE AND MAINTENANCE
Only basic cleaning should be required to maintain the screens at
their best. A soft cloth can be used for cleaning the units. Typical
window cleaner or rubbing alcohol can also be used to clean the
glass portion of the video screen display. Do not use harsh or abra-
sive cleaners on the unit.
Avoid contact between sharp or hard objects and the video touch
screen because this can result in scratches or other permanent
marks on the screen. Clean only with a soft cloth, using window
cleaner or rubbing alcohol only. Never use harsh or abrasive clean-
ers on the unit, as this may result in damage to the unit that is not
covered under warranty.
BASIC NAVIGATION FEATURES
All features are easily accessible through the quick access keys,
touch point commands and menus. Some navigation is linked
between the 4.5” touch screen and the 7” touch screen, with data
shared between the units.
