2017 OWNERS MANUAL / 156
There are also areas in which sliding a finger from side to side will
scroll through a list. When the slider bar on top of the screen is
visible, sliding the finger across it will change screens.
NOTE: While the slide area may appear to be curved, it is, in fact, a
straight line.
AUDIO
The Audio screen can be accessed by pressing the Audio Quick
Access Key on the HV700. Press any Quick Access Key to exit this
screen.
Touch Point Commands
POWER — Turns stereo system on/o.
SOURCE — Touch this to select a connected
source. MasterCraft supports the following
devices:
• FM radio
• AM radio
• Sat
• iPod / USB
• DVD
• VHF
• Sirius XM Radio
• Auxiliary
• Regional Weather Channel
VOLUME — Touch this button to lower the volume.
VOLUME — Touch this button to raiser the volume.
VOLUME — Touch this button to mute the volume.
PREV TRACK — Plays the previous track current CD.
NEXT TRACK — Plays the next track of the current CD.
The ProStar 7” video touch screen is a multi-functional tool that
provides GPS tracking, multi-media display, cruise control, rider
profiles, and enables equipment operators to view a wide range of
engine, ballast, transmission parameters and service codes.
CARE AND MAINTENANCE
Only basic cleaning should be required to maintain the 7” video
touch screen at its best. A soft cloth can be used for cleaning the
units. Typical window cleaner or rubbing alcohol can also be used to
clean the glass portion of the video screen display. Do not use harsh
or abrasive cleaners on the unit.
Avoid contact between sharp or hard objects and the video touch
screen because this can result in scratches or other permanent
marks on the screen. Clean only with a soft cloth, using window
cleaner or rubbing alcohol only. Never use harsh or abrasive clean-
ers on the unit, as this may result in damage to the unit that is not
covered under warranty.
BASIC NAVIGATION FEATURES
All features are easily accessible through the quick access keys,
touch point commands and menus.
Quick Access Keys
The following controls are accessed via the Quick Access Keys:
Audio, Ballast/Trim, Gauges, Video, Settings Menu, GPS, User
Profiles, Cruise ON/OFF, Increase Value and Decrease Value. These
Quick Access Keys allow easy and convenient access to the most
used screen functions on MasterCraft boats.
Touch Point Commands
After the desired screen is accessed, navigation within the screen
is controlled with Touch Point Commands. These are executed by
touching the screen in areas that are outlined with a highlighted bezel.
In addition, there are areas where sliding a finger up or down can
adjust settings. For example, on the Ballast and Tabs screen, sliding
the finger on the screen on the inside of the tank area adjusts the
ballast setting.
