2017 OWNERS MANUAL / 158
BALLAST & TRIM
The Ballast and Tabs screen can be accessed by pressing the Bal-
last/Trim Quick Access Key on the HV700. Press any Quick Access
Key to exit this screen. This screen displays the current state of the
ballasts and trim tabs.
NOTE: We are showing one Ballast on the Ballasts screen. Your
dealer sets this option at 0, 1, or 2 Ballasts to fit your boat package.
Refer to the following chart for actions using the Touch Commands
on this screen.
Touch to turn cruise control ON or OFF.
Touch and slide your finger to change screens.
Touch to stop all activity on this screen.
Touch to turn AUTO LAUNCH/EXIT ON or OFF.
When Auto Launch is on, it automatically
controls the center tab. When speed is above
the Auto Launch speed the center tab will be
retracted to 0% or if a profile is selected, it
deploys the center tab to the profile setting. If
the speed is above the Auto Launch speed and
then decelerated below the Auto Launch speed,
the tab deploys to 100 (crossover speed).
Touch to save the settings to the current rider
profile.
NOTE: If no rider profile is selected, this does
nothing.
Touch to save these settings to a new rider pro-
file. A keyboard is displayed to name the new
profile and the new profile process is launched.
(See the Profiles section starting on page 10.)
Touch to fill all ballasts.
SCAN/STOP — Enables and stops the scanning
of available channels.
REWIND — Touch this button to rewind the
current selection.
FAST FORWARD — Touch this button to fast
forward the current selection.
STEREO SETTINGS — Displays the following
settings screen:
Utilize the + and – buttons to adjust the settings.
iPod MENU — Touch this button to display the
iPod menu, as shown below:
Utilize the Up and Down arrows, then touch
Select when the appropriate choice is displayed.
Zone Volume — Control the volume in the four
zones of the boat by sliding your finger to the
right or left on each line.
