cutting wheel and ejects it into the waste tank on the starboard side
of the boat via a short run of premium sanitation hose.
Toilet system start-up
1. Turn on fresh water pump switch at the helm side panel.
2. Press “Flush” switch and hold for at least 10 seconds.
3. Toss several sheets of toilet paper into bowl and repeat cycle. The
bowl should completely clear.
Normal flushing
FLUSHING TOILET
Press “Flush” switch (bottom switch) down and hold until waste
drains from toilet bowl (about 10 – 20 seconds). This switch acti-
vates a macerator pump that siphons water and waste from the
bowl, macerates, and propels the effluent to the discharge line/
holding tank.
Do not flush waste with “Dry Bowl” Switch! To maintain proper
cleanliness and operation of the toilet and macerator pump, water
should be used with every flush.
Toilet operation when connected to tank
monitor system
A tank watch monitor is located in the head module on the vanity
face. It has LED indicators that show empty, low, medium and full.
Never flush the toilet if the indicator shows the holding tank is full.
Empty the waste tank using dockside pump-out or optional over-
board discharge (3 miles offshore).
