2016 OWNERS MANUAL / 069
FEATURES
01. Bow cleat
02. Anchor
03. Ladder (where equipped)
04. Horn
05. Bow filler cushion (where equipped)
06. KGB ballast tank (beneath floorboard)
07. Circuit breaker panel (on kick panel beneath
instrument panel)
08. Nav/anchor light
09. Fuel tank filler
10. Instrument panel (details in Video Display
Gauge section)
11. Steering wheel
12. Fire suppression unit manual override
13. Midship cleat
14. Shift/throttle control
15. Heated seat (where equipped)
16. Cooler (under seat)
17. Stern light receptacle
18. Engine compartment
19. Stern cleat
port and starboard near transom)
20. Ballast tank
21. Automatic fire extinguisher
22. Shower (where equipped)
23. Freshwater flush port (where equipped)
24. Underwater lights (two, where equipped,
under swim platform)
25. Swim platform
26. Transom drain plug (center beneath
swim platform)
27. Bow cleat
28. Adjustable mirror
29. Amp
30. Hand-held fire extinguisher (inside)
31. Nav/anchor light
32. Fuel tank filler
33. iPod interface (inside, where equipped)
34. Glove box
35. Midship cleat
36. Observer seat (heated, where equipped)
37. Jump seat
38. Center drain plug (access plate under lid)
39. Subwoofer
40. Batteries (including ON-OFF switch)
41. Ballast tank
42. Stern cleat
43. Blower exhaust (two, on top of port and
starboard deck near transom)
44. Stereo remote (where equipped)
45. Freshwater tank fill
46. Washdown connection (where equipped)
47. Wake adjustment plate (under swim
platform, where equipped)
48. Transom rail with tow eye
49. Under-platform ladder (where equipped)
SPECIFICATIONS
Length of Boat 24’0”
Width Amidship 102”
Boat Weight 5,400 lbs.
Length of Boat w/Platform 26’ 1”
Towing Length 29’ 9”
Towing Width 102”
Fuel Capacity 74 gallons
Maximum Capacity 13 people
or 1,852 lbs.
Bow: 5 people or 700 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
