Maytag MDE2400AY Series User Manual

14 16023432 Rev. 0 ©2004 Maytag Services
To avoid risk of electrical shock, personal injury or
death; disconnect power to unit before servicing.
Disassembly Procedures
WARNING
!
Top Removal
1. Disconnect power supply to unit.
2. Remove 2 screws from dryer back.
3. Slide Top Cover to the rear of the dryer and separate
from cabinet.
Thermostat Removal
1. Disconnect power supply to unit.
2. Remove Top Cover.
3. Remove screws and Heater Shield.
4. Remove screws and Thermostats.
Resetable Thermal Hi-Limit
Fuse
Back Cover and Vent Tube Removal
1. Disconnect power supply to unit.
2. Remove 3 screws and Back Cover.
FRONT
OF
DRYER
SLIDE
