R
if the camera lenses are dirty or covered
R
if the vehicle components in which the cam-
eras are installed are damaged. In this event,
have the camera position and setting checked
at a qualified specialist workshop
Do not use the 360° camera in this case. You
can otherwise injure others or cause damage to
objects or the vehicle.
Guide lines are always shown at road level.
The field of vision and other functions of the
camera system may be restricted due to addi-
tional accessories on the rear of the vehicle (e.g.
license plate holder, bicycle rack).
On vehicles with height-adjustable chassis,
depending on technical conditions, leaving the
standard height can result in:
R
inaccuracies in the guide lines
R
inaccuracies in the display of generated
images (top view)
Activation conditions
The 360° camera image can be displayed if:
R
your vehicle is equipped with a 360° camera
R
the SmartKey is in position 2 in the ignition
lock
R
the multimedia system is switched on
Switching on the 360° camera
X
Press the Ø button in the center console
for longer than two seconds.
Depending on whether position D or R is
engaged, the following is shown:
R
a split screen with top view and the image
from the front camera or
R
a split screen with top view and the image
from the rear view camera
or
X
Press the Ø button in the center console.
The vehicle menu is displayed.
X
Select 360° Camera and press 7 to confirm.
Depending on whether position D or R is
engaged, the following is shown:
R
a split screen with top view and the image
from the front camera or
R
a split screen with top view and the image
from the rear view camera
Activating the 360° camera using
reverse gear
The 360° camera images can be automatically
displayed by engaging reverse gear.
X
Make sure that the SmartKey is in position 2
in the ignition lock.
X
Make sure that the Activation by R gear
function is selected in the multimedia system
(see the separate operating instructions).
X
To show the 360° camera image: engage
reverse gear.
The multimedia system shows the area
behind the vehicle in split-screen mode. You
see the top view of the vehicle and the image
from the rear view camera.
Selecting the split-screens or 180° view
Selecting split-screen view
X
To switch to the line with the vehicle icons:
slide 5 the controller.
X
To select one of the vehicle icons: turn 3
the controller.
X
To switch to 180° View: turn 3 the con-
troller to select 180° View
and press 7 to
confirm.
i
The 180° View option is only available in the
following views:
R
Top view with picture from the rear view
camera
R
Top view with picture from the front camera
Displays in the multimedia system
Important safety notes
The camera system may show a distorted view
of obstacles, show them incorrectly or not at all.
Obstacles are not shown by the system in the
following locations:
R
under the front and rear bumpers
R
very close to the front and rear bumpers
R
in the area immediately above the tailgate
handle
R
very close to the exterior mirrors
R
in the transitional areas between the various
cameras in the virtual top view
222
Driving systems
Driving and parking
