X
To close: clip in cover : on the front of the
dashboard.
X
Fold cover : inwards until it engages.
Fuse box in the engine compartment
Pay attention to the important safety notes
(
Y page 384).
G
WARNING
When the hood is open and the windshield
wipers are set in motion, you can be injured by
the wiper linkage. There is a risk of injury.
Always switch off the windshield wipers and
the ignition before opening the hood.
!
Make sure that no moisture can enter the
fuse box when the cover is open.
!
When closing the cover, make sure that it is
lying correctly on the fuse box. Moisture seep-
ing in or dirt could otherwise impair the oper-
ation of the fuses.
X
Open the hood (Y page 356).
X
Use a dry cloth to remove any moisture from
the fuse box.
X
To open: open clamps ;.
X
Fold up cover : in the direction of the arrow
and remove it.
X
To close: check whether the seal is seated
correctly in cover :.
X
Insert cover : at the side of the fuse box into
the retainers.
X
Fold down cover : and close clamps ;.
X
Close the hood.
Fuse box under the rear bench seat
Pay attention to the important safety notes
(
Y page 384).
!
Make sure that no moisture can enter the
fuse box when the cover is open.
!
When closing the cover, make sure that it is
lying correctly on the fuse box. Moisture seep-
ing in or dirt could otherwise impair the oper-
ation of the fuses or the cover could be dam-
aged by the rear bench seat.
X
Fold the right-hand rear bench seat forward
(
Y page 332).
X
To open: lift and fold out carpet : in the
direction of the arrow.
X
Release clamps ; by pressing them in the
direction of the arrow.
X
Fold cover = up in the direction of the arrow
and remove it.
i
The fuse allocation chart is located under
cover =.
Fuses
385
