X
Turn the SmartKey to position 2 in the igni-
tion lock (Y page 125).
X
Vehicles with a stowage compartment
cover: press the lower section of cover :.
The stowage compartment opens.
X
Press in cigarette lighter ;.
Cigarette lighter ; will pop out automati-
cally when the heating element is red-hot.
12 V sockets
General notes
X
Turn the SmartKey to position 1 in the igni-
tion lock (Y page 125).
The sockets can be used for accessories with
a maximum draw of 180 W (15 A). Accessories
include such items as chargers for mobile
phones.
If you use the sockets for long periods when
the engine is switched off, the battery may dis-
charge.
An emergency cut-out ensures that the on-
board voltage does not drop too low. If the on-
board voltage is too low, the power to the
sockets is automatically cut. This ensures that
there is sufficient power to start the engine.
Socket in the front center console
X
Vehicles with a stowage compartment
cover: press the lower section of the cover.
The stowage compartment opens.
X
Lift up the cover of the socket.
Socket in the rear passenger compart-
ment center console
X
Pull the cover out by the top of the handle
edge.
X
Lift up the cover of the socket.
Socket in the cargo compartment
X
Lift up the cover of socket :.
Mercedes me connect
General notes
A license agreement must be in place in order
to activate the Mercedes me connect service.
Make sure that your system is activated and
operational. To register, press the ï MB
Info call button. If any of the steps mentioned
are not carried out, the system may not be
activated.
If you have questions about the activation,
contact one of the following telephone hot-
lines:
R
USA: Mercedes-Benz Customer Assistance
Center at 1-800-FOR-MERCedes
(1-800-367-6372) or 1-866-990-9007
R
Canada: Customer Service at
1-888-923-8367
Shortly after successfully registering with the
service, a user ID and password will be sent to
you by post.
USA only: you can use this password to log
onto the Mercedes me connect area under
"Owners Online" at http://www.mbusa.com.
260
