MAINTENANCE
SECTION 5
CMD-3967823 / 90-865237030 OCTOBER 2003 Page 63
CE463
Filling
1. If necessary, add specified automatic transmission fluid through the dipstick threaded
hole to bring the level up to the MAXIMUM mark on the dipstick.
IMPORTANT: Use only specified Automatic Transmission Fluid (ATF).
a
b
c
d
79465
a-Dipstick
b-Threaded hole
c-MAXIMUM Fluid Level
d-MINIMUM Fluid Level
Model
Capacity
liters (U.S. qts)
Fluid type
ZF Marine 25A 1.8 (1.9)
1
Dexron III Automatic Transmission
Fluid or Equivalent
1
Always use the dipstick to determine the exact quantity of oil or fluid required.
NOTE: If the transmission fluid level was extremely low, contact your authorized Cummins
MerCruiser Diesel dealer/distributor.
2. Install the dipstick.
IMPORTANT: To accurately check the fluid level, the engine must be run at 1500 rpm
for 2 minutes immediately prior to checking the level.
3. Refer to Transmission Fluid - Checking.
