5.
Heavy‑duty propeller hub ‑ Install the propeller hub, propeller, washer,
Belleville washer, washer, and propeller nut onto the shaft.
a - Propeller nut
b - Washer
c - Belleville washer
d - Washer
e - Propeller
f - Propeller hub
6. Place a block of wood between the gearcase and the propeller. Tighten
the propeller nut to the specified torque.
Description
Nm lb‑in. lb‑ft
Propeller nut 75 – 55
Spark Plug Inspection and Replacement
1.
Remove top and rear cowls. Refer to Cowl Removal and Installation.
2. Disconnect the wiring harness from the pencil coil connections.
3. Remove screws securing the coils.
