11. Connect the wire harness to the pencil coil.
a - Wiring harness connector
b - Pencil coil
c - Screw
12. Install the rear and top cowls.
Fuses
IMPORTANT: An ATC fuse has the fuse element enclosed or sealed inside the
plastic housing. This type of fuse must be used for marine applications. Marine
applications are exposed to environments that may have the potential to
accumulate explosive vapors. ATO fuses have exposed elements and should
never be used in marine applications.
The electrical wiring circuits on the outboard are protected from overload with
fuses. If a fuse is blown, try to locate and correct the cause of the overload. If
the cause is not found, the fuse may blow again.
Remove the fuse puller from the holder.
