10
Safety
Pr
ecautions
Installa
tion
Requirements
Installa
tion
Instructions
DRAIN CONNECTION HEIGHT
The dr
ain connection method depends on the height of the drain hose
connection.
IMPORTANT: Failure to connect the drain hose at a height of 18" with air
gap (not provided) OR to create a drain loop with a minimum height of
32" (81.3 cm) will result in improper draining of the dishwasher.
WA
TER SUPPLY REQUIREMENTS
•
Wa
ter pressure from the hot water supply line must be between
20-120 psi (138-862 kPa).
•
Wa
ter heater that is adjusted to a water temperature of 120°F to 150°F
(49°C to 65.5°C).
•
A 90° elbow is r
equired to be attached to the water valve, prior to the
connection of the water line.
•
A
" min. diameter c
opper tubing water line extending at least 24"
(61 cm) from the rear wall, and routed to connect to the front left-hand
side of the dishwasher.
•
A hand shut-off valv
e in an accessible location, such as under the sink
(optional, but strongly recommended).
ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
•
Installa
tion and service must be performed by a
qualified installer or service agency.
•
Alwa
ys disconnect the power before servicing this unit.
•
This applianc
e must be properly grounded.
•
Failur
e to do so could result in death, fire, or electrical
shock.
IMPORTANT:
•
The dish
washer must be supplied with 120 volt, 60 Hz., and connected
to a dedicated, properly grounded branch circuit, protected by a 15 or
20 ampere circuit breaker or time delay fuse.
•
Maximum of two field wiring supply c
onductors (12 AWG Maximum)
plus one grounding conductor are permitted in the terminal box.
•
Use Only copper wir
e.
•
Wiring mus
t be 2-wire with ground.
•
Use a UL List
ed/CSA Approved metallic strain relief.
•
Be sure tha
t the electrical connection and wire size are adequate and
in conformance with the National Electrical Code, ANSI/NFPA No.
70-latest edition and all local codes and ordinances.
•
If the electrical supply does not meet the abov
e requirements, call a
licensed, qualified electrician before proceeding.
