26
Safety
Pr
ecautions
Installa
tion
Requirements
Installa
tion
Instructions
6. Connect the wir
es as follows using UL listed wire nuts of the
appropriate size to connect power cord to 16-gauge dishwasher wire.
Terminal box wire:
white
black
ground
connector
Power supply wire:
white
black
ground wire
NOTES:
•
Use cUL/UL lis
ted wire nuts of the appropriate size
to connect the power cord to 16-gauge dishwasher
wiring.
•
Insert wir
e ends into the wire nut. Do not pre-twist
bare wire.
•
Twis
t the wire nut.
•
Gently tug on wir
es to be sure both wires are
secured.
a
b
c
a
Ground
b
White
c
Black
7. Tight
en strain relief screws to secure the power cord.
8. Gently guide the wire nuts into the junction box, and then replace the
junction box cover making sure to not pinch the wires.
CONNECT T
O WATER SUPPLY
IMPORTANT: Handle and reposition the copper tubing gently; it bends
and kinks easily.
1. Connect the water supply line to the 90° elbow.
•
Slide the nut onto c
opper tubing, approximately 1" (2.5 cm) from
the end, and then slide the ferrule onto the tubing. Do not position
the ferrule on the end of the tubing.
•
Insert the copper tubing int
o the elbow as far as it will go.
To Next Page
