Safety
Pr
ecautions
Installa
tion
Requirements
Installa
tion
Instructions
3. Install a UL lis
ted/CSA approved strain relief.
4. Route the direct wire cable in the channel on the right-hand side of the
dishwasher base. Make sure that the dishwasher is not resting on and/
or pinching the wire.
5. Pull direct wire through strain relief in terminal box.
a
a
Str
ain Relief
6. Connect the wires as follows using UL listed wire nuts of the
appropriate size to connect direct wire to 16-gauge dishwasher wire.
Terminal box wire:
white
black
ground
connector
Power supply wire:
white
black
ground wire
NOTES:
•
Use UL lis
ted wire nuts of the appropriate size
to connect your household wiring to 16-gauge
dishwasher wiring.
•
Insert wir
e ends into twist on connector. Do not
pre-twist bare wire.
•
Twis
t connector.
•
Gently tug on wir
es to be sure both wires are
secured.
a
b
c
a
Ground
b
White
c
Black
7. Tight
en strain relief screws to secure cord.
8. Reinstall terminal box cover with wire nuts inside terminal box.
9. Make sure wires are not pinched by cover.
a
b
c
a
Ground
b White
c Black
