Midea VRF Service Manual

Two-way Cassette MCAC-VTSM-2016-05
28 Indoor Unit
3. Dimensions Unit :in(mm)
26-25/32(680)
46-5/32(1172)
2-1/4(57)
5-3/32(129)
27-19/32(701)
11-25/32
(299)
1-23/32(44)
7-9/16
(192)
11-25/32
(299)
3-19/32(91)
2(51)
6-23/32(171)
6-15/16
(176)
4-23/32
(120)
7-9/32(185)
9-1/2(241)
4-3/32
(104)
17-5/32(436)
3-19/32
(91)
23-9/32(591)
1-23/32(44)
56-5/16(1430)
5-3/32
(129)
1-25/32(45)
10-1/8(257)
4-19/32
(117)
4-29/32(
125)
6-5/16(
160)
5-3/32
(129)
27-19/32(701)
1-23/32(44)
5-15/16
(151)
20-15/32(520)
47-17/32(1207)
1-1/4(32)
1-1/4(32)
56-5/16(1430)
26-25/32(680)
46-5/32(1172)
23-9/32(591)
25/32(20)
54-23/32(1390) 25/32(20)
Fresh air
connector
The ceil opening
54-23/32*25-3/16 1390*640
1-13/16~2-5/32
(46~55)
13/32(10)
25-3/16(640)
25/32
(20)
25/32(20)
Water pump outlet
Electronic expansion
valve inspection hole
Water inlet hole and the water
level switch inspection hole
Lifting lug
Liquid side connecting pipe
Air side connecting pipe
Maintenance water outlet
Indoor unit
Fresh air connector
Both sides reserved air outlet
Lifting lug
Panel
