Midea VRF Service Manual

MCAC-VTSM-2016-05 Compact Four-way Cassette
Indoor unit 45
3. Dimensions
Unit: in(mm)
0-19/32(523)(Hook-location)
22-7/16(570)(Body)
25-15/32(647)(Panel)
Drain side
Unit: in(mm)
21-15/32(545)(Hook-location)
22-7/16(570)(Body)
25-15/32(647)(Panel)
A
2-3/8(60)
Ceiling
Panel
Hook
A
10-1/4(260)
Nut
Body
23-3/8(600)
1-31/32(50)
