Loading the dishwasher
55
Adjusting the upper basket
In order to gain more space for taller
items in the lower basket or upper
basket, the upper basket can be
adjusted on 3 levels with 3/4" (2cm)
between each level.
The upper basket can also be set at an
angle so that water can run off freely
from recesses. Make sure, however,
that the basket can slide smoothly in
and out of the wash cabinet.
 Pull out the upper basket.
To raise the upper basket:
 Lift the basket up until it clicks into
place.
To lower the upper basket:
 Pull upwards on the levers at either
side of the upper basket.
 Adjust the basket to the desired
height and then push the levers
securely back down into position.
When adjusting the upper basket,
make sure that tall plates in the lower
basket do not block the middle spray
arm.

Miele G7966SCVI Specifications

General

Built-in display	Yes
Display type	TFT
Inlet hose length	1.5 m
Outlet hose length	1.5 m
Place settings	16
Noise level	42 dB
Number of washing programs	10
Delayed start timer	Yes
Delayed start (max)	24 h
AquaStop function	Yes
Child lock	Yes
Water consumption per cycle	8.9 L
Power consumption (off)	0.3 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Width	598 mm
Depth	570 mm
Height	805 mm
Appliance placement	Built-in
Product size	Full-size
Washing programs	Eco
Drying system	AutoOpen drying
Energy efficiency class	A
Connected load	2.1 kW
Programs	Automatic, ECO, Intensive, Normal, Quick wash
Special features	AutoOpen drying
