All building in instructions given are
for a right hand hinged appliance.
If you have converted the appliance
to left hand hinging you will need to
adapt these instructions accordingly.
Align the housing unit
Before installing the appliance the
housing unit must be carefully aligned
using a spirit level. The unit corners
must be at right angles, as otherwise
the furniture door will not align correctly
with the 4 corners of the appliance.
Prepare the appliance
^ Fit cover strip a into position.
^ With 16 mm thick unit walls:
Shorten the sealing strip b to the
height of the niche.
Stick the sealing strip to the side of
the appliance on which the door is
opened.
Clip the spacer piece c over the
hinges.
Building in the appliance
28
