10
Pellerin Milnor Corporation
BNWHUH02 / 2021344
BNWHUH02 0000369527 8/18/21 4:18 PM Released
2.2 Use the Red Safety Supports for Maintenance —
48040M7K, 68036M5K, 72044M5K
BNWHUH02.C02 0000373217 A.5 A.3 8/17/21 11:08 AM Released
2.2.1 What Safety Supports are Provided and Why
BNWHUH02.C01 0000373218 A.5 A.6 8/18/21 3:40 PM Released
These machines are provided with two, permanently attached safety stands that can be folded
down from within a channel on the shell (drum) when the machine is in the wash position. If the
machine has a load chute for automatic loading, it is also provided with a safety bar that can be
inserted when the load chute is raised. The safety supports provide protection against the drifting
down of the vertically moving portion of the machine during maintenance in the event of a leak
in the hydraulic system. They are not intended to restrain the machine from coming down under
power. Use the safety support(s) whenever the maintenance to be performed requires you to place
any part of your body in or near the path of the vertically moving portion of the machine.
WARNING: Incorrect use of the safety supports — can cause the machine to descend
and crush you.
� Never work near the path of the vertically moving portion of the ma-
chine unless the safety supports are deployed and power is removed from
the machine.
� Do not use power to close a small gap between the machine and the
safety supports. Use care not to lower the machine with the safety supports
deployed.
� Where a pair of safety supports is provided, always use both supports.
� Maintain the safety support(s) in good condition.
� When not in use, stow the safety support(s) in the location(s) provided on the machine
or in a convenient, designated location.
Safety
To Next Page
