Milnor MWF C Series User Manual

12
Pellerin Milnor Corporation
2.2.3 How To Deploy the Safety Stands — 48040M7K
BNWHUH02.T01 0000373179 A.5 A.6 8/18/21 4:13 PM Released
1. Use the Manual mode to put the machine in the wash position (shell is horizontal).
2. Remove the clevis pins and allow the stands to pivot down completely. See the illustration be-
low left.
3. Insert the clevis pins and secure them with the cotter pins. See the illustration above right.
4. Remove electric power from the machine.
2.2.4 How to Deploy the Load Chute Safety Bar
BNWHUH02.T03 0000373443 A.5 A.6 8/18/21 4:18 PM Released
1. Use the Manual mode to raise the load chute completely.
2. See the illustration at right. Insert one end of the safety bar
in the holding bracket on the load chute, then the other end
in the bracket on the front of the machine.
3. Remove electric power from the machine.
Safety
