Pellerin Milnor Corporation 21
Table 6. Motor Grease Schedule
Motor Identifica-
tion (example: main
drive)
Interval
Quantity
Dates When Grease is Added
Years Hours
fl oz mL
.
3.1.1.7 Mechanisms and Settings
BNUUUH01.R14 0000399409 A.5 A.26 A.11 11/16/21 11:14 AM Released
Make sure mechanisms are serviceable and settings are correct to prevent unsatisfactory
performance.
Table 7. Mechanisms and Settings
Mark
Do this each
Component
More Data
1 2 3 4
5 6
x
2400 hours controller circuitry Examine wiring and connections in electrical boxes.
Look for corrosion, loose connections. See Section
3.1.2 , page 21
x
200 hours water pressure regulator
for optional supply
injector
See Figure 11, page 30. Value: 28 PSI (193 kPa).
x
200 hours water pressure regulator
for chemical flush
See Figure 13, page 31. Value: 28 PSI (193 kPa).
x
200 hours compressed air
mechanisms
See Section 3.2.5 , page 32
x
200 hours bath level sensor that uses
air pressure
Examine the air tube and connections. See Figure 12,
page 31
x
200 hours air pressure for bearing
housing
See Figure 16, page 33 Value: 10 PSI (69 kPa)
x
200 hours hydraulic line pressure See Figure 25, page 41. Approximate maximum pres-
sure in operation = 700 PSI (48 bar).
3.1.2 How To Remove Contamination
BNUUUH01.R03 0000335794 A.5 A.26 A.2 2/18/21 10:13 AM Released
Table 8. Contamination Types, Cleaning Agents, and Procedures
Material or
Component
Usual
Contamination
Example Cleaning Agent
More Data
machine housing dust, dirt
—
compressed air or
shop vacuum
Air—no more than 30 psi (207 kpa).
Do not push dust in mechanisms.
fins and vents on
electrical
components
dust motors, inverters,
braking resistors
shop vacuum, soft
bristle brush, canned
air for electrical
components
Do not push dust in mechanisms.
electric box
interior
dust all electric boxes
Routine Maintenance
