4-30 BeneLink Module Operator’s Manual
Monitor output: alarms from Draeger Infinity V500 Ventilator
Priority Label
Low
Alarm following alarms:
Exp. hold interrupted
CO2 measurement failed
CO2 sensor ?
Plow>high limit
Plow<low limit
PMIN REACHED
4.8 Draeger Savina 300
4.8.1 Output Signals—Parameters
Monitor output: parameters from Draeger Infinity V500 Ventilator
Label Description Trend, record, print
Monitoring Parameters
Cdyn Dynamic compliance Yes
Rdyn Dynamic lung resistance Yes
Pmean Mean pressure Yes
PEEP Positive end-expiratory pressure Yes
Ppeak Peak pressure Yes
Vte Expiratory tidal volume Yes
Vti Inspired tidal volume Yes
MV Minute volume Yes
ftot Total respiratory rate Yes
MVspn Spontaneous breathed minute volume Yes
fspn Spontaneous respiratory rate Yes
FiO2
Fractional concentration of O
2
in inspired
gas
Yes
T Inspiratory breathing gas temperature No
