4-64 BeneLink Module Operator’s Manual
Monitor output: parameters from Hamilton Galileo (Polling Protocol) Ventilator
Label Description Trend, record, print
O2% Oxygen concentration No
Phigh Upper pressure level No
I: E Inspiratory time:Expiratory time ratio No
Peak Flow Peak flow No
Exp% Inspiration termination level No
Ramp Ramp No
IBW Ideal body weight No
%MinVol
Percentage of minute volume to be
delivered
No
4.14.2 Output Signals – Alarms
Monitor output: alarms from Hamilton Galileo (Polling Protocol) Ventilator
Priority Label
Physiological alarms
High
Paw High
Apnea
Loss of PEEP
MV Low
MV High
Medium RR High
Technical alarms
High
Disconnection ventilator side
Patient Disconnected
High
Technical
alarms
If the monitor shows the alarm [High Technical
alarms], the external device may have the alarm:
Fail to Cycle.
