Mindray BeneLink User Manual
4
of 1
of 1 rating
227 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
7-2
Ben
eLink Modul
e Operator
’
s Manual
7.1.
2
Output Signa
ls
–
Ala
rm
s
Mon
itor o
utp
ut
: al
arm
s fr
om
M
asim
o R
adic
al
7 P
ul
s
e C
O
-
Ox
imet
er
Prio
ri
ty
Lab
el
Ph
ysi
ol
o
gic
al al
ar
ms
High
Resp
irato
ry Pau
se
Sp
O2
High
Sp
O2
Low
PR High
PR Lo
w
S
p
CO
H
i
gh
S
p
CO L
ow
SpME
T
High
S
pME
T
Lo
w
SpHb Hig
h
S
pH
b
Low
S
p
OC
H
i
gh
S
p
OC
L
ow
RR Hi
gh
RR Lo
w
ORI H
igh
ORI L
ow
M
e
di
um
PI High
PI Low
PI
Delt
a Hi
gh
PI Delt
a low
PVI High
PVI Low
Tch
n
i
cal
al
ar
m
s
High
No Cable C
o
nne
cted
177
179
Table of Contents
Default Chapter
9
Table of Contents
9
1 Safety
17
Safety Information
17
Warnings
18
Cautions
18
Notes
19
2 Interfacing with External Devices
21
Benelink Introduction
21
Physical Specifications
21
Data Transmission
22
Supported Devices
22
Supported Anesthesia Machines
22
Supported Ventilators
23
Supported Tcgas Monitoring Devices
25
Supported Infusion System (for Benevision N Series Monitors Only)
25
Supported Other Devices
26
Connecting External Devices Via DIAP Protocol
26
Monitors Only)
26
Configuring the ID Adapter
27
Connecting External Devices
28
Accessories
30
3 Integrating the Anesthesia Machine
31
Draeger Apollo
31
Output Signals-Parameters
31
Output Signals-Alarms
34
Output Signals - Waveforms (for Benevision N Series Monitors Only)
38
Draeger Fabius GS /Fabius Tiro
39
Output Signals - Parameters
39
Output Signals - Alarms
41
Draeger Perseus A500
43
Output Signals-Parameters
43
Output Signals-Alarms
45
Output Signals - Waveforms (for Benevision N Series Monitors Only)
49
GE Aespire 7900&7100/Aestiva 7900&7100
50
Output Signals - Parameters
50
Output Signals - Alarms
51
Output Signals - Waveforms (for Benevision N Series Monitors Only)
54
GE Aespire View (for Benevision N Series Monitors Only)
54
Output Signals - Parameters
54
Output Signals - Alarms
56
Output Signals - Respiratory Loops
57
GE Aisys/ Aisys Cs2/Avance
57
Output Signals - Parameters
57
Output Signals - Alarms
59
Output Signals - Waveforms (for Benevision N Series Monitors Only)
61
MAQUET FLOW-I
61
Output Signals - Parameters
61
Output Signals - Alarms
64
Mindray
66
Output Signals - Parameters
66
Output Signals - Alarms
69
Output Signals - Waveforms (for Benevision N Series Monitors Only)
76
4 Integrating the Ventilator
77
Carefusion Avea (for Benevision N Series Patient Monitor Only)
77
Output Signals - Parameters
77
Output Signals - Alarms
80
Output Signals - Waveforms
82
Carefusion Vela
82
Output Signals - Parameters
82
Output Signals - Alarms
84
Draeger Babylog 8000 Plus/Babylog 8000
86
Output Signals-Parameters
86
Output Signals-Technical Alarms
87
Draeger Babylog VN500
87
Output Signals-Parameters
87
Output Signals - Alarms
89
Draeger Evita 2
92
Output Signals - Parameters
92
Output Signals - Alarms
94
Draeger Evita2 Dura/Evita 4/Evita XL
95
Output Signals - Parameters
95
Output Signals - Alarms
98
Output Signals - Waveforms (for Benevision N Series Monitors Only)
100
Draeger Infinity V500
101
Output Signals-Parameters
101
Output Signals-Alarms
103
Draeger Savina
106
Output Signals-Parameters
106
Output Signals-Alarms
108
GE Carescape R860
110
Output Signals-Parameters
110
Output Signals - Waveforms (for Benevision N Series Patient Monitor Only)
113
Output Signals - Respiratory Loops
113
Monitor Only)
113
Output Signals-Alarms
113
GE EngströM Carestation
118
Output Signals - Parameters
118
Output Signals - Alarms
121
Hamilton
125
Output Signals - Parameters
125
Output Signals - Alarms
127
Hamilton G5 (Block Protocol)
128
Output Signals - Parameters
128
Output Signals - Alarms
130
Output Signals - Waveforms (for Benevision N Series Monitors Only)
135
Hamilton G5 (Polling Protocol)
135
Output Signals - Parameters
135
Output Signals - Alarms
137
Hamilton Galileo (Polling Protocol)
138
Output Signals - Parameters
138
Output Signals - Alarms
140
MAQUET SERVO-I/Servo-S
141
Output Signals - Parameters
141
Output Signals - Alarms
144
Output Signals - Waveforms (for Benevision N Series Only)
146
Output Signals - Loops (for Benevision N Series Only)
146
Maquet Servo-U/Servo-N
147
Output Signals-Parameters
147
Output Signals-Alarms
149
Output Signals-Waveforms (for Benevision N Series Monitor Only)
151
Output Signals-Respiratory Loops (for Benevision N Series Monitor Only)
151
Newport E360
152
Output Signals - Parameters
152
Output Signals - Alarms
153
Philips Respironics V60 (SNDA Protocol)
156
Output Signals - Parameters
156
Output Signals - Alarms
157
Philips Respironics V60 (VRPT Protocol)
158
Output Signals - Parameters
158
Output Signals - Alarms
158
Puritan Bennett PB840/PB980 (SNDF Protocol)
160
Output Signals - Parameters
160
Output Signals - Alarms
162
Puritan Bennett PB840/PB980 (SNDA Protocol)
163
Output Signals - Parameters
163
Output Signals - Alarms
165
Resmed VSIII (for Passport M Series Only)
166
Output Signals-Parameters
166
Output Signals-Alarms
166
5 Integrating the Tcgas Monitoring Device
169
Biometer TCM Combim/Tcm Tosca/Tcm40
169
Output Signals - Parameters
169
Output Signals - Alarms
170
Biometer TCM4 (for Benevision N Series Monitors Only)
170
Output Signals - Parameters
170
Output Signals - Alarms
171
Sentec Digital Monitor
171
Output Signals - Parameters
171
Output Signals - Alarms
172
6 Integrating Infusion System (for Benevision N Series Monitors Only)
173
B.braun Perfusor Space Pumps
173
Output Signals - Parameters
173
Fresenius Agilia Injectomat Infusion Pumps
173
Output Signals - Technical Alarms
174
Fresenius Agilia Volumat Infusion Pumps
175
Output Signals - Parameters
175
Output Signals - Technical Alarms
175
7 Integrating Other Devices
177
Masimo Radical 7 Pulse CO-Oximeter (for Benevision N Series Monitors Only)
177
Output Signals - Parameters
177
Output Signals - Alarms
178
Organon TOF-Watch SX NMT Monitoring Device
180
Output Signals - Parameters
180
Output Signals - Alarms
180
8 Connecting External Devices Via DIAP Protocol
181
Only)
181
Setting Parameter Output Properties
181
Setting the ID of the ID Adapter
181
Parsing the Monitor Data
181
9 Benelink Function Test
183
Preparing the Tools
183
Checking the Function
183
Setting the Serial Ports
185
Setting the Serial Ports of the Anesthesia Machines
185
Setting the Serial Ports of the Ventilator
186
Setting the Serial Ports of the Tcgas Monitoring Devices
189
Setting the Serial Ports of the Pumps
190
Setting the Serial Ports of Other External Devices
191
Troubleshooting Device Integration Failures
192
Benelink Installation and Test Report
193
10 Alarm ID of External Devices (for Benevision N Series Monitors Only)
195
Alarm Ids of Anesthesia Machines
195
Alarm Ids of Ventilators
199
Alarm Ids of the Pulse CO-Oximeter
202
Alarm Ids of Tcgas Monitoring Devices
207
Alarm Ids of NMT Monitoring Device
207
Alarm Ids of Infusion Systems
208
