BeneLink Module Operator’s Manual 8-1
8 Connecting External Devices via DIAP Protocol (For BeneVision N
Series Monitors only)
8.1 Setting Parameter Output Properties
You must configure the DIAP protocol to realize communications between the monitor
and the third party device. To do so, proceed as follows:
1. Select the [Main Menu] quick key → from the [System] column select
[Maintenance]→ input the required password → select
.
2. Select the [
Others] tab →[Parameter Output Setup].
3. Set the [Baud Rate], [Parity Mode], [Data Bits] or [Stop Bits] as desired.
8.2 Setting the ID of the ID Adapter
The ID of the DIAP protocol is 6000a000. For the method of setting the ID, refer to 2.5
Configuring the ID Adapter.
8.3 Parsing the Monitor Data
To parse the monitor data, refer to “DIAP Communication Protocol Service Manual (PN:
KF-H-0070-10-0307)”.
