BeneLink Module Operator’s Manual 4-87
Monitor output: alarms from Puritan Bennett PB840/PB980 (SNDF Protocol)
Ventilator
Priority Label
Low
Low
Technical
alarms
If the monitor shows the alarm [Low Technical
alarms], the external device has one or more of the
following alarms: Inoperative Battery
Low Battery
AC LOSS
Tinsp too Long
4.21 Puritan Bennett PB840/PB980 (SNDA Protocol)
4.21.1 Output Signals – Parameters
Monitor output: parameters from Puritan Bennett PB840/PB980 (SNDA Protocol)
Ventilator
Label Description Trend, record, print
Monitoring Parameters
Ppeak Peak pressure Yes
Pplat Plateau pressure Yes
Pmean Mean pressure Yes
VTe Expiratory tidal volume Yes
MVspn Spontaneous breathed minute volume Yes
MVe Expiratory minute volume Yes
ftot Total respiratory rate Yes
Rstat Static lung resistance Yes
Rdyn Dynamic lung resistance Yes
Cstat Static compliance Yes
Cdyn Dynamic compliance Yes
PR Pulse rate Yes
