Comments and Body Marks 9-7
z Rotate the <Angle/Steer> knob to adjust the orientation.
z Tap [Save Probe] to save the current probe mark direction and position for the
body mark.
4. Press <Set> to confirm the position and orientation of the probe marker and exit
body mark mode.
9.2.3 Moving Body Marks
You can move the body mark graphics to any desired position within the image area.
1. Roll the trackball to move the cursor onto the body mark. The cursor changes into
, indicating you can move the pictogram to a new position.
2. Press <Set> key to select the body mark, and a frame will appear around the
graphics.
3. Roll the trackball to move the body mark to the desired position.
4. Press <Set> to anchor and confirm the new graphics position.
NOTE: In Dual B Mode, a body mark cannot be moved between the separated image
windows.
9.2.4 Deleting Body Marks
îš„ To delete a body mark
(1) Use the trackball to position the cursor on the body mark graphic and Press <Set>
to select.
(2) Press <Clear> to delete the selected body mark.
NOTE: In the Body Mark mode, if no object is selected, pressing the [Clear] key
will clear all comments, body marks and general measurements from the
screen.
Tips:
z Powering off, preset returning, switching the exam/ patient/ mode/ probe will
clear the body marks.
