6-6
6.6 Rear Cover Assembly
Exploded View
Parts List
SN
P/N
Description
Qty
1 0000-10-43076
Speaker
1
2 0850-20-30708
Socket
fixture
2
3
M04-0510
60---
T
apping screw M2X8
4
4
0852-20-77425
W
aterproof seal 2
2
5 M04-021000-
--
Flat
washer
1
6 0852-2077432
Spring
1
7 0852-20-77407
Rear
cover
1
8 0852-20-77410
Lock
pin
1
9 0852-20-77420
Leaf
3
1
47
