Trio™ Operating Instructions 0070-10-0666-01 6 - 9
Appendix Patient Parameter Specifications
6.2.5 ECG Respiration Performance Requirements
6.2.6 NIBP Sub-System Performance Characteristics
The NIBP function is capable of providing systolic, diastolic, and mean blood pressure
measurements in Pediatric and Adult modes non-invasively, using a blood pressure cuff. It
operates over the pulse rate range of 40 to 240 bpm.
The NIBP function is in accordance with the requirements of EN 60601-2-30, EN 1060-1,
EN 1060-3 and ANSI/AAMI SP-10:1992.
Resolution: 1 bpm
Accuracy: ± 1 bpm or ± 1% whichever is greater.
Trigger Threshold Level: 200 μV (Lead II)
Trigger Indication: There is an audible beep on every beat
captured
Sensing Leads: Lead II
Source: 3-lead or 5-lead ECG Cable.
Range: Adult: 6 to 120 breaths per minute
Pediatric: 6 to 150 breaths per minute
Accuracy: ± 2% or ± 2 breaths per minute, whichever
is greater
Excitation:
≤ 300 μA RMS max.
Bandwidth: 0.2 Hz to 2 Hz (-3 dB) for all patient sizes
Baseline Impedance Range: 200 Ω to 2500 Ω at patient with 1 kΩ
resistor in the ECG cable.
Linear Signal Range: 3 Ωp-p minimum
Noise: less than 0.05 Ω at 500 Ω patient
impedance, using a standard ECG cable
Min. Breath Height Detected: Function of respiration scale. Waveform
needs to be greater than 0.3 Ω in order for
breaths to be accurately detected.
Cardiovascular Artifact Rejection: Detected by algorithm
Sweep speed: 6.25 mm/s, 12.5 mm/s, 25 mm/s
