Part II General Information

Structure and Assembly/Disassembly 175

5 Structure and Assembly/Disassembly

5.1 System Structure

5.1.1 Main Unit

Figure 5-1 Explosive view of the main unit

No. Name No. Name

1 LCD 6 Equipment body

2 Spindle cover 7 Dustproof Net

3 Control panel 8 Li-ion battery

4 Control Panel to Main Board

Connecting Cable

9 Battery Chamber Cover

5 SSD cover plate
