WALL-MOUNTED MSZ-HC•VA/B SeriesM series
OPERATION AND ACTUATOR CONTROL
WALL-
MOUNTED
C-221
NOTE : Last setting will be stored after the unit is turned OFF with the remote controller. Indoor unit receives the signal of the
remote controller with beeps.
WIRELESS REMOTE CONTROLLER
MSZ-HC25VA MUZ-HC25VA
MSZ-HC35VA MUZ-HC35VA
MSZ-HC35VABH MUZ-HC35VABH
Time set buttons
RESET button
Vane control button
Signal transmitting section
Operation display section
Temperature buttons
ON/OFF (operate/stop) button
Fan speed control button
Operation select button
Timer mode select button
ECONO COOL button
INDOOR UNIT DISPLAY SECTION
Operation Indicator lamp
The operation indicator at the right side of the indoor unit indicates the operation state.
• The following indication applies regardless of shape of shape of the indication.
Indication Operation state Room temperature
The unit is operating to
reach the set temperature
About 2°C or more away
from set temperature
The room temperature is
approaching the set tem-
perature
About 1 to 2°C from set
temperature
Lighted
Blinking
Not lighted
C.1.10.4 MSZ-HC•VA/VAB Series
To Next Page
