Mitsubishi Electric MFZ-KA35VA User Manual

WALL-MOUNTED Cooling OnlyM series
C-5
SPECIFICATIONS
WALL- MOUNTED
C.1.1 SPECIFCATIONS
C.1.1.1 Cooling Only
Model Name Indoor Unit MSC-GE20VB-E1 MSC-GE25VB-E1 MSC-GE35VB-E1 MS-GE50VB-E1
Outdoor Unit MU-GA20VB-E3 MU-GA25VB-E2 MU-GA35VB-E3 MU-GE50VB-E1
Power Supply Source
Out V 230 230 230 230
Phase
㪪㫀㫅㪾㫃㪼 㪪㫀㫅㪾㫃㪼 㪪㫀㫅㪾㫃㪼 㪪㫀㫅㪾㫃㪼
Hz 50 50 50 50
In V 230 230 230 230
Phase
㪪㫀㫅㪾㫃㪼 㪪㫀㫅㪾㫃㪼 㪪㫀㫅㪾㫃㪼 㪪㫀㫅㪾㫃㪼
Hz 50 50 50 50
Refrigerant R410A R410A R410A R410A
Cooling Capacity Rated kW 2.3 2.5 3.45 5.0
SHF 0.74 0.70 0.66 0.65
Total Input Rated kW 0.715 0.775 1.120 1.810
EER 3.22 3.23 3.08 2.76
EEL RANK A A B D
SPL In Low dB(A) 25 25 26 34
Mid dB(A) 31 31 33 38
Hi dB(A) 36 36 40 42
Out Rated dB(A) 45 45 49 52
Air Volume In Low
m
3
/min.
4.6 5.1 5.4 8.6
Mid
m
3
/min.
6.2 6.4 7.4 10.7
Hi
m
3
/min.
7.9 7.9 9.7 12.8
Out Rated
m
3
/min.
30.0 30.0 31.7 31.7
Max. Running Current A 5.7 5.6 8.3 12.0
Indoor Unit Input Rated kW 0.035 0.035 0.040 0.060
Max. Running Current A 0.5 0.5 0.5 0.5
Dimensions Height mm 278 278 278 325
Width mm 815 815 815 1100
Depth mm 244 244 244 258
Weight kg 9 9 10 16
Breaker Size A 10 10 10 10
Outdoor Unit Dimensions Height mm 550 550 550 550
Width mm 800 800 800 800
Depth mm 285 285 285 285
Weight kg 27 27 34 38
Max. Running Current A 5.2 5.1 7.8 11.5
Breaker Size A 10 10 10 15
Ext. Piping Diameter Liquid mm 6.35 6.35 6.35 6.35
Gas mm 9.52 9.52 9.52 12.70
Max. lengh Out-In Total m 20 20 25 25
Max. Height Out-In Below Indoor m 10 10 10 10
Above Indoor m 10 10 10 10
Out Cooling Upper Limit
o
C
+43 +43 +43 +43
Lower Limit
o
C
+21 +21 +21 +21
Guranteed
Operation
Range
Indoor/outdoor separate power supply

Mitsubishi Electric MFZ-KA35VA Specifications

General

Brand	Mitsubishi Electric
Model	MFZ-KA35VA
Category	Air Conditioner
Language	English
