1. Product Specifications
1-2. External Dimensions
QAHV-N136TAU-HPB (-BS)
Unit: mm (in.)
19(3/4)
755(29-3/4)
26
54(2-3/16)54(2-3/16)
26
9(3/8)
1474(58-1/16)
303
206(8-1/8)
274(10-13/16)
297(11-3/4)
85
90(3-9/16)
85
122(4-13/16)
199(7-7/8)
719(716~722)
530(20-7/8)
1060(41-3/4)
(755(29-3/4))
18(3/4) 18(3/4)
74(2-15/16)
74(2-15/16)
1777(70)
(488(19-1/4))
187(7-3/8)
(24(1))
54(2-3/16)
MORE THAN 50(2)
MORE THAN 50(2)
MORE THAN 500(19-11/16)
MORE THAN 300(11-13/16)
760(29-15/16)
1220(48-1/16)
(11-15/16)
(3-3/8)
(3-3/8)
(MOUNTING PITCH)
(28-5/16(28-1/4~28-7/16))
(MOUNTING PITCH)
(1-1/16)
(1-1/16)
SERVISE
PANEL
39
(1-9/16)
BACK VIEWFRONT VIEW
BOTTOM VIEW
TOP VIEW
SERVICE SPACE
RIGHT SIDE VIEW
DISCHARGE
AIR
INTAKE
AIR
INTAKE
AIR
INTAKE
AIR
The specification of the product is for the improvement
a previous notice and might change.
Note.
Please install the drain pan because defrosting water or
dew condensation water drops from holes on the unit base.
<Accessory>
•Rc3/4 to NPT3/4
adapter <Brass> ··· 2 pcs.
VENTILATION SPACE
DRAIN OUTLET(*1)
ø
38.1(1-1/2)
HOLE TO PASS ROPE
FOR CARRYING
CONTROL BOX
<SUB>
DISPLAY
CONTROL BOX
<MAIN>
DRAIN OUTLET
(WATER PIPE)
HOLES FOR TRANSMISSION CABLE
ø
35(1-7/16) KNOCKOUT HOLE
HOLE FOR POWER SUPPLY
ø62(2-1/2)
KNOCKOUT HOLE
HOT WATER
OUTLET<Rc3/4>
WATER INLET<Rc3/4>
(*1)
2×2-14×31
(9/16×1-1/4)
OVAL HOLE
Rc3/4
NPT3/4
VENTILATION • SERVICE SPACE
<PLAN>
