-76-
8 MOUNT ASSEMBLY
8 DISASSEMBLY EXPLANATORY DRAWING
8.1 Indoor unit
8.1.1 SRK25QA-S
RAC-SRK25QA-S-HEAT& EXCH&CONTROL
NO.
Part No
Parts
RE.Q
1-8
RYD301A055A
HEAT EXCH ASSY(AIR)
1
2
RYD315D013
HEADER ASSY
1
3
RYD321A061
PIPE
1
4
RYD129A053
BRACKET ASSY(L)
1
5-7
RYD321A049C
PIPE ASSY
1
6
RYG323F002
UNION,SOLDER
1
7
RYG323F002A
UNION,SOLDER
1
8
RYD129A038
PLATE,BAFFLE
1
9
RYD142A037
BOX,CONTROL
1
10-16
RYD501A068J
CONTROL ASSY
1
10-12
RYD505A055B
PWB ASSY
1
11
RYG555B002A
VASTOR
1
12
RYS564A001
FUSE(CURRENT)
1
13
RYD551A009A
SENSOR ASSY
1
14
RYD566A094
CORD,POWER
1
15
RYG561B001A
BLOCK,TERMINAL
1
16
RYD011G018A
LABEL,WIRING
1
