Mitsubishi Heavy Industries SRK25QA-S User Manual

-86-
8.2 Outdoor unit
8.2.1 SRC25QA-S
SRC25QA-S-HEAT EXCH&CONTROL
NO.
Parts No
Parts Name
RE.Q
1
RYF301A042
HEAT EXCH ASSY(AIR)
1
2-10
RYF304A156F
PINING ASSY(4WAY)
1
2
RYF325A005
PIPE,SHELL
1
3
RYC325A001
PIPE,SHELL
1
4
RYF382C010
VALVE,S(4WAY)
1
5-7
RYF304A109B
PIPING ASSY(EXPAN)
1
5
SSA387F062
VALVE,BODY(EXP)
1
6
RYF315B048
CAPILLARY
1
7
RYG357A003
STRAINER
1
8
RYF116A008
BRACKET,VALVE
1
9
RYF381A070
VALVE,SERVICE(1/4")
1
10
RYF381A069
VALVE,SERVICE(3/8")
1
11
RYF154D009B
INSULATION,COMP
1
12
RYF154D013
INSULATION,COMP
1
13
RYF154D037
INSULATION,COMP
1
14
RYF154D011A
INSULATION,COMP
1
15
RYF382F013
COIL,SOLENOID
1
16
SSA382F220
COIL,SOLENOID
1
