6A1 ENGINE (E-W) -
Timing Belt
11A-4-2
REMOVAL AND INSTALLATION <MIVEC>
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
11 Nm
12 Nm
9Nm
48 Nm
44 Nm
49 Nm
35 Nm
88 Nm
17
17
11 Nm
11 Nm
11 Nm
11 Nm
19
20
21
22
23
22 Nm
18
9Nm
9Nm
Removal steps
1. Timing belt front cover, upper right
2. Timing belt front cover, upper left
3. Timing belt front cover, lower
4. Engine support bracket
5. Angle sensor
6. Angle sensor
7. Spacer
A
A
""
D
A 8. Timing belt
9. Tensioner pulley
10. Tensioner arm
11. Tensioner spacer
"
B
A 12. Auto tensioner
13. Crankshaft sprocket
14. Sensing plate
15. Washer
A
B
""
A
A 16. Camshaft sprocket bolt
17. Camshaft sprocket
18. Camshaft sprocket with sensing
plate
19. Idler pulley
20. Timing belt rear cover, left
21. Timing belt rear cover, right
22. Timing belt rear cover, center
23. Connector bracket
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
