6A1 ENGINE (E-W) -
Oil Pump Case and Oil Pan
11A-13-6
(3) Check the body clearance.
Standard value: 0.10 - 0.18 mm
Limit: 0.35 mm
OIL LEVEL SENSOR (FOR EUROPE)
(1) Put the oil level sensor in the oil, then move the float
up and down with the oil at a temperature either lower
than 40°C or higher than 80°C, and check for continuity.
40
°
C
Float position
Switch ON/OFF
Condition when down ON (continuity)
Condition when up ON (continuity)
80
°
C
Float position
Switch ON/OFF
Condition when down OFF (no continuity)
Condition when up ON (continuity)
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
6AE0090
6AE0192
