5. FUEL AND EMISSION CONTROL PARTS
REMOVAL AND INSTALLATION <SOHC>
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
18 Nm
9Nm
22 Nm
23 Nm
12 Nm
18 Nm
9Nm
12 Nm
18 Nm
18 Nm
18 Nm
7
Removal steps
1. Air intake plenum stay, front
2. Air intake plenum stay, rear
3. EGR valve
4. Gasket
5. Vacuum pipe
6. Throttle body
"
C
A 7. Gasket
8. Air intake plenum
9. Gasket
10. Control harness
11. Delivery pipe and injector
12. Insulator
13. Insulator
"
B
A 14. Injector
15. Grommet
16. O-ring
17. Fuel pipe
18. O-ring
"
A
A 19. Fuel pressure regulator
20. O-ring
21. Delivery pipe
22. Alternator bracket
PWEE9622
