Function Blocks 6
6 - 76
Setup of the Delayed Alternate Function Block directly from the α2 Series Controller
1 ) Allocate the input pin to be used for the function block.
2 ) Press the “OK” key with the cursor in the function block. The function block edit screen is
displayed as shown.
3 ) Press the “OK” key to set the Time unit for the delayed alternate output. Choose either a
10ms, 100ms or 1s time interval using the “ and ” keys to highlight the option and press
the “OK” key when ready.
4 ) Return to the function block edit screen. Using the “ and ” keys highlight the Setup FB
and press the “OK” key.
5 ) Press the “OK” to accept subsequently use the “ESC” key to return to the FBd.
B001 : D LA
Time uni
Cha nge No
De l e t e FB
t
Se t up FB
Time uni t
100 sm
10 ms
1s
De l a y iTme
.01s
t= .00s
T=
B001 : D LA
