9 - 31
9. ERROR CODE LIST
9.6 Error Code List for the QCPU-A (A Mode)
Meanings and causes of error message, error codes, detailed error codes and corrective
actions are described.
Table 9.5 Error Code List for the QCPU-A (A Mode)
Error Massage
Error
Code
(D9008)
Detailed
Error
Code
(D9091)
CPU
States
Error and Cause Corrective Action
"INSTRCT
CODE ERR."
(Checked when
STOP RUN
or at execution
of instruction.)
10 101 STOP Instruction codes which the CPU
module cannot decode are included in
the program.
(1) Read the error step using a peripheral
device and correct the program of the
step.
(2) Check the ROM if it contains
instruction codes which cannot be
decoded. If it does, replace it with a
correct ROM.
102 Index qualification is specified for a 32-
bit constant.
Read the error step using a peripheral
device and correct the program of the
step.
103 Device specified by a dedicated
instruction is not correct.
104 A dedicated instruction has incorrect
program structure.
105 A dedicated instruction has incorrect
command name.
106 Index qualification using Z or V is
included in the program between
and .
107 (1) Index qualification is specified for
the device numbers and set values
in the OUT instruction of timers and
counters.
(2) Index qualification is specified at the
label number of the pointer (P)
provided to the head of destination
of the , , , ,
, and
instructions or at the
label number of the interrupt pointer
(I) provided to the head of an
interrupt program.
108 Errors other than 101 to 107 mentioned
above.
"PARAMETER
ERROR"
(Checked at
power on and
at STOP/
PAUSE
RUN.)
11 111 STOP Capacity settings of the main and sub
programs, microcomputer program, file
register comments, status latch,
sampling trace and extension file
registers are not within the usable
range of the CPU.
Read parameters in the CPU memory,
check the contents, make necessary
corrections and write them again to the
memory.
112 Total of the set capacity of the main and
sub programs, file register comments,
status latch, sampling trace and
extension file registers exceeds
capacity of the memory cassette.
113 Latch range set by parameters or
setting of M, L or S is incorrect.
114 Sum check error
LEDA/B IX
LEDA/B IXEND
CJ SCJ CALL CALLP
JMP
LEDA/B FCALL
LEDA/BBREAK
