Mitsubishi PLK-E03BT User Manual

－41－
Ref.1 <Table cut-out for PLK-E03BT machine>
Ref.2 <Table and stand>
720
800
~
mm
3
5
8
8
0
5
Note: Apply rubber plate
to a control box
16
21
18
17
15
14
3
19
15
15
22
1
26
24 23 25
20
16
17
18
2
6
3
27 28
29
16
17
18
10
11
12
13
9
8
16
17
18
2
3
7
4
5
14
19
Fig.No Description Q ty.
1 Table Top 1
2 S tand (A ) 2
3 S tand (B ) 2
4 S upport fram e (A ) 1
5 S upport fram e (B ) 1
6Bolt w ith S W - P W (large) M 8x20 6
7Bolt w ith S W - P W (sm a ll) M 8 x 2 0 4
8Bolt w ith S W - P W (m iddle) M 8x20 2
9Wide-rim m ed w asher (large) 8 2
10 P edal 1
11 Shaft 1
12 S haft housing 2
13Collar 2
14Bolt w ith S W M 8 x2 0 2
15 T nut M 8 2
16 Top cap 4
17 W asher M 124
18 S pacer 4
19Caster 4
20 W ood screw 5.8x32 4
21 C ontrol box 1
22 M ounting bolt M 8 x 6 0 8
23 W ide-rim m ed w asher (large) 8 11
24 W ide-rim m ed w asher 8 11
25 N ut M 8 11
26 R ubber plate 1
27 M otor 1
28 P ow er box 1
29 M ounting bolt M 8 x 7 0 13
30 D raw er 1
31 Rail2
32 W ood screw 4.5x38 4
33 S taple (L) 1
34 S w itch assem bly 1
35 W ood screw 4.1x162
36 S taple (S) 5
