－1－
1. STRUCTURE OF THE SEWING MACHINE
PLK-E03BT electronic bar tack machine is constructed with the following main parts.
2
3
4
6
7
1
5
8
9
Start switch / Work holder switch
Machine head
Halt switch
Table top
Thread Stand
Operation panel
(optional)
Servo-motor
Steel stand
Control
box
