3
SEQUENCE PROGRAM CONFIGURATION AND
EXECUTION CONDITIONS
3 - 1
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
CHAPTER3 SEQUENCE PROGRAM CONFIGURATION
AND EXECUTION CONDITIONS
There are three types of programs that can be executed in the CPU module: sequence
program, SFC program, and ST program.
This manual does not explain the SFC program and ST program.
Refer to the following manuals for the SFC program and ST program.
QCPU (Q Mode)/QnACPU Programming Manual (SFC)
QCPU (Q Mode) Programming Manual (Structured Text)
(1) Program execution order of Basic model QCPU
The Basic model QCPU executes a program in the following order (Figure 3.1).
Figure 3.1 Program execution order of Basic model QCPU
Initial processing
I/O module refresh processing
Program operation processing
END processing
To Next Page
