1.1.2 Features of High Performance model QCPU
The features specific to the High Performance model QCPU are described below.
(1) High performance and large capacity
The High Performance model QCPU is a module targeted for small-scaled to large-
scaled systems and capable of high-speed massive data processing.
The High Performance model QCPU realizes construction of the optimum and high-
performance system.
Figure 1.3 System example using the High Performance model QCPU
Ethernet
High Performance model QCPU
CC-Link remote
I/O station
CC-Link remote
device station
GX Developer
MELSECNET/H remote I/O network
CC-Link IE controller network
MELSECNET/H PLC to PLC network
